In the past few years, you may have heard of terms like shadow DOM and virtual DOM. These, although of course related to the original DOM, refer to very different concepts. In this article, I will cover what, exactly, the shadow DOM is and how we can use it.
Shadow DOM serves for encapsulation. Both the CSS and DOM can be encapsulated so that they are hidden from the rest of the page. What a shadow DOM does is let you create a new root node, called #shadow-root, that is hidden from the main document.
However, even before we jump into the concept of a shadow DOM, let's try to look at what a normal DOM looks like. Any page with a DOM follows a tree structure. Here I have the DOM structure of a very simple page:
In the above image, #document is the root node for this page.
You can find out the root node of a page by typing document.querySelector('html').getRootNode() in the browser console.
If you try to get the child nodes of an HTML tag using document.querySelector('html').childNodes in the browser console, then you can see the following:
This shows that the DOM follows a tree structure. You can go deeper into these nodes by clicking on the arrow right next to the name of the node. And just like how I have shown in the screenshot, anyone can go into a particular node by expanding it and change these values. In order to achieve the encapsulation, the concept of a shadow DOM was invented.
View Website
View Website
View Website
For example, let's say that instead of having text inside the <p> tag in the preceding example, we have a shadow host that is attached to a shadow root. The code looks like this:
<!-- index.html -->
<!DOCTYPE html>
<html>
<head>
<title>Light Dom</title>
</head>
<body>
<h1>This is a heading</h1>
<p></p>
<script src="script.js"></script>
</body>
</html>
//script.js
let shadowRootEl = document.querySelector('p');
let shadowRoot = shadowRootEl.attachShadow({mode: 'open'});
let newEl = document.createElement('span');
newEl.innerText = "This is span tag";
shadowRoot.appendChild(newEl);
The call to elem.attachShadow({mode: …}) creates a shadow tree.
The mode option sets the encapsulation level. It must have any of two values:
-
open – the shadow root is available as
elem.shadowRoot. -
closed –
elem.shadowRootis always null.
The shadow root, returned by attachShadow, is like an element: we can use innerHTML or DOM methods, such as append, to populate it.
The updated DOM structure:
What you see under #shadow-root is called shadow DOM. Furthermore, if you tried to get the child nodes of this <p> tag, you would see something like this:
Notice that even though the <span> tag is present inside the <p> tag, the #shadow-root does not let JavaScript APIs touch it. This is how the shadow DOM encapsulates code inside itself.
Summary
Shadow DOM is a way to create a component-local DOM. The elements defined inside it are invisible to JavaScript selectors from the main document. To get elements in shadow tree, we must query from inside the tree. But unlike the DOM, the shadow DOM is not based on a full, standalone document. A shadow DOM, as the name suggests, is always attached to an element within a regular DOM. Without the DOM, a shadow DOM doesn't exist.
